TMS320C5515
SPRS645F – AUGUST 2010 – REVISED OCTOBER 2013
www.ti.com
Table 5-15. Switching Characteristics Over Recommended Operating Conditions for EMIF Asynchronous Memory (1) (2)
Figure 5-21 ) (4)
CV DD = 1.05 V
(3)
(see Figure 5-19 and
NO.
PARAMETER
MIN
DV DDEMIF = 3.3/2.75/2.5/1.8 V
NOM
MAX
UNIT
READS and WRITES
1
t d(TURNAROUND)
Turn around time
(TA)*E - 13
(TA)*E
(TA)*E + 13
ns
READS
3
4
5
6
7
8
9
10
11
t c(EMRCYCLE)
t su(EMCEL-EMOEL)
t h(EMOEH-EMCEH)
t su(EMBAV-EMOEL)
t h(EMOEH-EMBAIV)
t su(EMBAV-EMOEL)
t h(EMOEH-EMAIV)
t w(EMOEL)
t d(EMWAITH-EMOEH)
EMIF read cycle time (EW = 0)
EMIF read cycle time (EW = 1)
Output setup time, EM_CS[5:2] low to EM_OE low (SS = 0)
Output setup time, EM_CS[5:2] low to EM_OE low (SS = 1)
Output hold time, EM_OE high to EM_CS[5:2] high (SS = 0)
Output hold time, EM_OE high to EM_CS[5:2] high (SS = 1)
Output setup time, EM_BA[1:0] valid to EM_OE low
Output hold time, EM_OE high to EM_BA[1:0] invalid
Output setup time, EM_A[20:0] valid to EM_OE low
Output hold time, EM_OE high to EM_A[20:0] invalid
EM_OE active low width (EW = 0)
EM_OE active low width (EW = 1)
Delay time from EM_WAITx deasserted to EM_OE high
(RS+RST+RH)*E - 13
(RS+RST+RH+(EWC*16))*E - 13
(RS)*E-13
-13
(RH)*E - 13
-13
(RS)*E-13
(RH)*E-13
(RS)*E-13
(RH)*E-13
(RST)*E-13
(RST+(EWC*16))*E-13
4E-13
(RS+RST+RH)*E
(RS+RST+RH+(EWC*16))*E
(RS)*E
0
(RH)*E
0
(RS)*E
(RH)*E
(RS)*E
(RH)*E
(RST)*E
(RST+(EWC*16))*E
4E
(RS+RST+RH)*E + 13
(RS+RST+RH+(EWC*16))*E +139
(RS)*E+13
+13
(RH)*E + 13
+13
(RS)*E+13
(RH)*E+13
(RS)*E+13
(RH)*E+13
(RST)*E+13
(RST+(EWC*16))*E+13
4E+13
ns
ns
ns
ns
ns
ns
ns
ns
ns
ns
ns
ns
ns
WRITES
EMIF write cycle time (EW = 0)
(WS+WST+WH)*E-13
(WS+WST+WH)*E
(WS+WST+WH)*E+13
ns
15
16
17
18
19
20
21
t c(EMWCYCLE)
t su(EMCSL-EMWEL)
t h(EMWEH-EMCSH)
t su(EMBAV-EMWEL)
t h(EMWEH-EMBAIV)
t su(EMAV-EMWEL)
t h(EMWEH-EMAIV)
EMIF write cycle time (EW = 1)
Output setup time, EM_CS[5:2] low to EM_WE low (SS = 0)
Output setup time, EM_CS[5:2] low to EM_WE low (SS = 1)
Output hold time, EM_WE high to EM_CS[5:2] high (SS = 0)
Output hold time, EM_WE high to EM_CS[5:2] high (SS = 1)
Output setup time, EM_BA[1:0] valid to EM_WE low
Output hold time, EM_WE high to EM_BA[1:0] invalid
Output setup time, EM_A[20:0] valid to EM_WE low
Output hold time, EM_WE high to EM_A[20:0] invalid
(WS+WST+WH+(EWC*16))*E - 13
(WS)*E - 13
-13
(WH)*E-13
-13
(WS)*E-13
(WH)*E-13
(WS)*E-13
(WH)*E-13
(WS+WST+WH+(EWC*16))*E
(WS)*E
0
(WH)*E
0
(WS)*E
(WH)*E
(WS)*E
(WH)*E
(WS+WST+WH+(EWC*16))*E +
13
(WS)*E + 13
+13
(WH)*E+13
+13
(WS)*E+13
(WH)*E+13
(WS)*E+13
(WH)*E+13
ns
ns
ns
ns
ns
ns
ns
ns
ns
(1)
(2)
(3)
(4)
Timing parameters are obtained with 10pF loading on the EMIF pins.
TA = Turn around, RS = Read setup, RST = Read strobe, RH = Read hold, WS = Write setup, WST = Write strobe, WH = Write hold, MEWC = Maximum external wait cycles. These
parameters are programmed via the Asynchronous Configuration and Asynchronous Wait Cycle Configuration Registers.
E = SYSCLK period in ns. For example, when SYSCLK is set to 100/120 MHz, E = 10/8.33 ns, respectively.
EWC = external wait cycles determined by EM_WAITx input signal. EWC supports the following range of values EWC[256-1]. Note that the maximum wait time before timeout is specified
by bit field MEWC in the Asynchronous Wait Cycle Configuration Register.
94
Peripheral Information and Electrical Specifications
Submit Documentation Feedback
Product Folder Links: TMS320C5515
Copyright ? 2010–2013, Texas Instruments Incorporated
